24 Pin DIP, TF Series, Up-to 15 Watts
In stock
Custom manufacturer 7 yrs CN
About Product
The TF series offer 15 watts of output power in a 24 pin standard DIP package. These converters have a 4:1 wide input voltage range of 9 to 36 Volts or 18 to 75 Volts. The converter provides precise regulated output voltage ranging from 3.3 to 15 volts. Other output voltages are also available and please contact DATEL if your application requires such modification.This series features high efficiency up to 90%; 1500Volts of DC of isolation and can operate over the ambient temperature range of –40°C to +85°C. These modules are fully protected against input Under Voltage Lock Out (UVLO), output short circuit and output overvoltage conditions.Please contact DATEL if you are in need for a power product that is not listed on our website.
| Item # | Minimum Input Voltage (V) | Maximum Input Voltage (V) | Output Voltage | Maximum Output Current (A) | Efficiency (%) | Data Sheet (PDF Link) |
|---|---|---|---|---|---|---|
| TF22S3.3-4 | 9 | 36 | 3.3 V | 4 | 88 | TF Series 24 Pin DIP |
| TF22S5-3 | 9 | 36 | 5 V | 3 | 90 | TF Series 24 Pin DIP |
| TF22S12-1.25 | 9 | 36 | 12 V | 1.25 | 90 | TF Series 24 Pin DIP |
| TF22S15-1 | 9 | 36 | 15 V | 1 | 90 | TF Series 24 Pin DIP |
| TF22D12-0.62 | 9 | 36 | ±12 V | ±0.62 | 90 | TF Series 24 Pin DIP |
| TF22D15-0.5 | 9 | 36 | ±15 V | ±0.5 | 90 | TF Series 24 Pin DIP |
| TF45S3.3-4 | 18 | 75 | 3.3 V | 4 | 88 | TF Series 24 Pin DIP |
| TF45S5-3 | 18 | 75 | 5 V | 3 | 90 | TF Series 24 Pin DIP |
| TF45S12-1.25 | 18 | 75 | 12 V | 1.25 | 90 | TF Series 24 Pin DIP |
| TF45S15-1 | 18 | 75 | 15 V | 1 | 90 | TF Series 24 Pin DIP |
| TF45D12-0.62 | 18 | 75 | ±12 V | ±0.62 | 90 | TF Series 24 Pin DIP |
| TF45D15-0.5 | 18 | 75 | ±15 V | ±0.5 | 90 | TF Series 24 Pin DIP |
Key attributes
Know your supplier
Website:https://www.datel.com/
Company Name:DATEL
Location:Mansfield, MA 02048
Description:ISO 9001:2015 certified. Manufacturer of standard & custom data acquisition systems and components. Products include sampling analog-to-digital converters, digital-to-analog converters, flash converters, sample & hold amplifiers, high speed wideband operational amplifiers, electronic imaging, multiplexers & power supplies. Industries served include scientific, medical, aerospace, HI-REL, defense, security and industrial applications. Meets ANSI/ESD S20.20-2007 standards. Meets MIL-PRF-38534 Class E, G, & H Spec.
