Timers
In stock
Custom manufacturer 7 yrs CN
About Product
0-5 minute timing range, spring wound electro-mechanical timer, used to time the shaker mechanism in bag type dust collectors. Contact rating single pole single throw rated 1 HP at 125 VAC. 8 Pin Repeat Cycle or “change over” timer used to cycle a device on and off, on and off until power is removed. Timing ranges 1 second – 10 seconds – 1 minute – 10 minutes – 1 hour – 10 hours – 100 hours. Contact rating double pole double throw. Maximum breaking current 8 amps. Operating voltage 24 VDC thru 240 VAC. 11 Pin Multi-Function timer, features many uses which include on delay, interval, off delay, one shot and repeat cycle easy selectable functions. Timing range .1 second thru 999 hours. Coil operating voltage 110 DC or 120 VAC. Contacts double pole double throw rated at 1/2 HP at 120 /240 VAC.8 Pin on delay timer, timing range 0-180 seconds time selectable with convenient dial knob. Coil voltage 120 VAC. Contacts rated 10 amps at 120 VAC or 30 VDC. Predetermining 3 digit counter,
| Item # | Item Name | Description |
|---|---|---|
| 6X545 | 0-5 Min Spring Wound Timer | 0-5 minute timing range, spring wound electro-mechanical timer, used to time the shaker mechanism in bag type dust collectors. Contact rating single pole single throw rated 1 HP at 125 VAC. Note: Contact stephens for all your electrical needs |
| 88-867-155 | Repete Cycle Timer 8 Pin | 8 Pin Repeat Cycle or “change over” timer used to cycle a device on and off, on and off until power is removed. Timing ranges 1 second – 10 seconds – 1 minute – 10 minutes – 1 hour – 10 hours – 100 hours. Contact rating double pole double throw. Maximum breaking current 8 amps. Operating voltage 24 VDC thru 240 VAC. Note: Contact stephens for all your electrical needs |
| 9050JCK70V20 | Multi-Function Timer 11 Pin | 11 Pin Multi-Function timer, features many uses which include on delay, interval, off delay, one shot and repeat cycle easy selectable functions. Timing range .1 second thru 999 hours. Coil operating voltage 110 DC or 120 VAC. Contacts double pole double throw rated at 1/2 HP at 120 /240 VAC. Note: Contact stephens for all your electrical needs |
| 1EGB9 | On Delay Timer 8 Pin 0-180 Seconds | 8 Pin on delay timer, timing range 0-180 seconds time selectable with convenient dial knob. Coil voltage 120 VAC. Contacts rated 10 amps at 120 VAC or 30 VDC. Note: Contact stephens for all your electrical needs |
| 366B400Q30PX | 3 Digit Counter | Predetermining 3 digit counter, set-point selectable 0-999 counts using three rotary knobs mounted on face of counter. Uses include but not limited to water measurement. Operating voltage 120 VAC, double pole double throw contacts, rated at 7 amps at 120 VAC. Note: 4 digit version available upon requestNote: Contact stephens for all your electrical needs |
Key attributes
Know your supplier
Website:https://www.stephensmfg.com/
Company Name:Stephens Mfg. Co., Inc.
Location:Tompkinsville, KY 42167
Description:Manufacturer of standard and custom process plants and concrete equipment. Modular type stationary, portable, rectangle, and in-truss silo plants are offered. Precast, prestress, block, and pipe product plants are also available. Dust collector, hopper, mixing, conveyor, reclaimer, and plant concrete machinery are provided. Aggregate bin, batcher, conveyor, electrical, screw, turnhead, chute, vent, and reclaimer parts are also offered. Made in the USA.
